Marantz SR9600 - Page 128

180
QF47 : MM1511XNRE
Q703, QO02 : M29W800DT70N1
AI05470B
19
A0-A18
W
DQ0-DQ14
V
CC
M29W800DT
M29W800DB
E
V
SS
15
G
RP
DQ15A–1
RB
BYTE
A0-A18 Address Inputs
DQ0-DQ7 Data Inputs/Outputs
DQ8-DQ14 Data Inputs/Outputs
DQ15A–1 Data Input/Output or Address Input
E
Chip Enable
G
Output Enable
W
Write Enable
RP
Reset/Block Temporary Unprotect
RB
Ready/Busy Output
(not available on SO44 package)
BYTE
Byte/Word Organization Select
V
CC
Supply Voltage
V
SS
Ground
NC Not Connected Internally
