To operate analog input control and monitoring:
1. Tap ANALOG INPUT from the Mode Selection Screen.  e Analog Input Mode Run Screen will be
displayed.
2. Tap EDIT
.  e Analog Input Mode Edit Screen will be displayed.
3. Tap the desired analog input type from the available list.
4. If using either ANALOG: VOLTAGE or ANALOG: CURRENT:
a. Select the desired current or voltage operating range from the available list.
b. Tap CONFIRM
to save or CANCEL to cancel and return to the previous screen.
NOTE:
• Tap STOP
on the pump drive touchscreen to override the remote control device and immediately stop
the pump operation. NOTE: If locked, the screen will need to be unlocked before the pump operation
can be stopped.
• See www.master ex.com for further information on using analog input remote control and monitoring.
Saving Analog Input Mode Settings as a New Program
Changes made to mode parameters can be saved as a new program for easier access to frequently used
mode settings. NOTE: If User Management is enabled only users with authorization can create and modify
programs (for further information see "User Management" on page 2-8).
T
o save mode parameters to a new program:
1. If required, edit the Analog Input Mode settings as desired.
2. Tap MODE NAME BANNER to return to the Mode Selection Screen.
3. Tap NEW PROGRAM. NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap
SCROLL
to view additional pages.
4. Tap ANALOG INPUT.  e Analog Input New Program Screen will be displayed with the last settings
used in the Analog Input Mode.
5. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
6. Tap CONFIRM to save or DELETE to cancel.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL
will display additional pages.
