4-8 Masterflex
®
I/P
®
MasterSense™ Process Drives
Section 4: Communication Specification
Masterflex
PROFIBUS DATA
e MASTERFLEX Pump Drive operates as a DP-V0 Slave.
GSD File: CPMP0FF8.GSD
ID Number: 0FF8 HEX
Default Slave Address: 7
Cyclic Input Data: 56 bytes
Cyclic Output Data: 28 bytes
Table 1 below lists the 56 bytes of cyclic input data, from pump to master.
Table 1
Cyclic Input (pump —> master, 56 bytes)
Data Size in Bytes Data Type
Pump Status 4 unsigned integer
Dispense Mode 1 unsigned integer
Tube Size 1 unsigned integer
Flow Units 1 unsigned integer
Padding (not used) 1 unsigned integer
Cumulative Volume 4 decimal floating-point
Remaining Dispense Volume 4 decimal floating-point
Remaining Dispense On Seconds 4 decimal floating-point
Remaining Dispense Off Seconds 4 decimal floating-point
Current Batch Count 4 unsigned integer
Total Batch Count 4 unsigned integer
Minimum Flow Rate 4 decimal floating-point
Current Flow Rate 4 decimal floating-point
Maximum Flow Rate 4 decimal floating-point
Remaining Dispense On Days 2 unsigned integer
Remaining Dispense On Hours 1 unsigned integer
Remaining Dispense On Minutes 1 unsigned integer
Remaining Dispense On Seconds 1 unsigned integer
Remaining Dispense On Tenths 1 unsigned integer
Remaining Dispense Off Days 2 unsigned integer
Remaining Dispense Off Hours 1 unsigned integer
Remaining Dispense Off Minutes 1 unsigned integer
Remaining Dispense Off Seconds 1 unsigned integer
Remaining Dispense Off Tenths 1 unsigned integer
