3-19 Masterflex
®
I/P
®
MasterSense™ Process Drives
Section 3: Operation
Masterflex
be displayed.
a. Enter the desired number of dispenses in a batch using the onscreen keypad. NOTE: If required, tap
INFINITE ∞ to select an in nite number of dispense cycles. If in nite is selected, the pump will run
continuously.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
10. If required, tap ANTI-DRIP.  e Anti-Drip Screen will be displayed (for further information see "Anti-
D
rip" on page 3-12).
a.
Tap ON or OFF to enable or disable the Anti-Drip feature.
b. If enabled, enter the desired degrees of reverse rotation using the onscreen keypad. NOTE: Typical
values range from 5 to 45 degrees.
c. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
11. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL
will display additional pages.
Adding a New Program: Analog Input Mode
To add a new Analog Mode program:
1. Tap NEW PROGRAM from the Mode Selection Screen.  e New Program Screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap SCROLL to view
additional pages.
2. Tap ANALOG INPUT.  e Analog Input New Program Screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
4. Tap INPUT.  e Analog Type Screen will be displayed.
5. Tap the desired analog type from the available list.
6. If using either ANALOG: VOLTAGE or ANALOG: CURRENT:
a. Select the desired current or voltage operating range from the available list.
b. Tap CONFIRM
to save or CANCEL to cancel and return to the Analog Input New Program
Screen.
7. Tap SIZE.  e Tube Size Screen will be displayed.
a. Select the desired tube size from the list of available options.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Analog Input New
Program Screen.
8. Tap DIRECTION to select either clockwise
or counterclockwise  ow direction.
9. Tap CONFIRM to save or DELETE to discard changes.
