Section 3: Operation
Masterflex
Saving Continuous Mode Settings as a New Program
Changes made to mode parameters can be saved as a new program for easier access to frequently used settings.
NOTE: If User Management is enabled only users with authorization can create and modify programs (for
further information see "
User Management" on page 2-8).
To save mode parameters to a new program:
1. If required, edit the Continuous Mode settings as desired.
2. Tap MODE NAME BANNER to return to the Mode Selection Screen.
3. Tap NEW PROGRAM. NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap
SCROLL
to view additional pages.
4. Tap CONTINUOUS.  e Continuous New Program Screen will be displayed with the last settings used
in the Continuous Mode.
5. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
6. Tap CONFIRM to save or DELETE to cancel.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL
will display additional pages.
