3-18 Masterflex
®
I/P
®
MasterSense™ Process Drives
Section 3: Operation
Masterflex
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL
will display additional pages.
Adding a New Program: Volume Mode
To add a new Volume Mode program:
1. Tap NEW PROGRAM from the Mode Selection Screen. e New Program Screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap SCROLL
to view
additional pages.
2. Tap VOLUME. e Volume New Program Screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
4. Tap VOLUME. e Dispense Volume Screen will be displayed.
a. Tap VOLUME and enter the desired volume using the onscreen keypad. NOTE: If the volume of
uid is unknown the pump drive can record uid dispense volumes (for further information see "
Vol-
ume Record
" on page 3-12).
b. Tap RAMP UP
to set the time the pump takes to reach full ow rate (between 0 and 60 seconds)
using the onscreen keypad.
c. Tap RAMP DOWN
to set the time the pump takes to stop at the end of each dispense operation
(between 0 and 60 seconds) using the onscreen keypad.
d. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
5. Tap INTERVAL TIME to set the amount of time the pump will pause between each operation. e
Interval Time Screen will be displayed. NOTE:
If the interval time is set to 0 (zero) the pump drive will
require a start input (from either the touchscreen or a wired input) to start the next dispense.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
6. Tap FLOW RATE. e Flow Rate Edit Screen will be displayed.
a. Tap UNITS to access the Flow Units Screen and select the desired ow unit from the available list.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the previous screen.
c. Tap FLOW and enter the desired ow rate using the onscreen keypad.
d. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
7. Tap SIZE. e Tube Size Screen will be displayed.
a. Select the desired tube size from the list of available options.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
8. Tap DIRECTION to select either clockwise
or counterclockwise ow direction.
9. Tap BATCH TOTAL to adjust the number of dispenses in each batch cycle. e Batch Total Screen will
To Next Page
