Masterflex I/P MASTERSENSE MFLX77421-00 - Using Program Modes; Editing a Program

3-20 Masterflex
®
I/P
®
MasterSense™ Process Drives
Section 3: Operation
Masterflex
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL
will display additional pages.
Using Program Modes
Custom programs will appear in alphabetical order at the bottom of the Mode Selection Screen. If there are
multiple programs tapping SCROLL
will display additional pages.
General Preparation:
• Con rm the correct tubing has been selected and is properly loaded into the pump drive (refer to the
pump head user manual for further information).
• Ensure the correct pump head and tube size have been selected (for further information see "Pump Head
S
election" on page 2-9).
• Con
rm all  uids and containers are ready.
• Switch the drive on using the power switch located at the rear of the drive. NOTE: If User Management
is enabled you may be prompted for a username and password (For further information see "User
M
anagement" on page 2-8). 
e touchscreen display will revert to the previously used operation mode.
• Con rm that the tubing has been calibrated by checking that Calibration Complete
is displayed on
the Program Information
Screen (for further information see "Tube Calibration" on page 2-11).
• If required, prime the pump before operation (for further information see "Priming the Pump Drive" on
page 2-10).
T
o use a program:
1. Select the desired program from the Mode Selection Screen.  e Program Run Screen will be displayed.
2. Tap START
to begin the pump drive operation using the displayed program settings.
3. If required, Tap PAUSE
or STOP during operation. NOTE:  e pump cannot be paused during
Continuous Mode operation.
NOTE:
• Tap INFORMATION
to view the selected program's settings.
• Individual settings cannot be edited from the Program Run Screen.
Editing a Program
NOTE: If User Management is enabled only users with authorization can create and modify programs (for
further information see "User Management" on page 2-8).
T
o edit a program:
1. Tap EDIT
located next to the desired program name on the Mode Selection Screen (NOTE: If there are
multiple programs, tap SCROLL
to display additional pages).  e Program Edit Screen will be displayed.
2. Edit the settings for the selected mode as desired. For instructions on editing individual mode settings see:
• "Adding a New Program: Continuous Mode" on page 3-16.
• "Adding a New Program: Time Mode" on page 3-16.
• "Adding a New Program: Volume Mode" on page 3-18.
