Masterflex I/P MASTERSENSE MFLX77421-00 - Table of Contents

iii Masterflex
®
I/P
®
MasterSense™ Process Drives Masterflex iii
Table of Contents
SECTION 1: INTRODUCTION 11
Safe Operation 1-1
About the Master ex I/P MasterSense
™ 1-2
Package Contents 1-2
Features 1-2
SECTION 2: BASIC SETUP & SETTINGS 21
Touchscreen Icons 2-2
Before Starting the Drive 2-3
Switching on the Drive 2-3
Settings 2-4
Language Settings 2-4
Setting the Time 2-4
Setting the Date 2-5
Display Brightness 2-5
Dispense Completion Alerts 2-5
Batch Completion Alerts 2-5
Analog Output 2-5
Device Information 2-6
Screen Saver 2-6
Device Name 2-6
WI-FI Settings 2-7
Ethernet Settings 2-7
User Management 2-8
Pump Head Selection 2-9
Auto Start 2-10
Priming the Pump Drive 2-10
Tube Calibration 2-11
Tube Calibration Screen 2-11
SECTION 3: OPERATION 31
Mode Selection Screen 3-1
Continuous Mode 3-2
Continuous Mode Run Screen 3-2
Continuous Mode Operation 3-3
Saving Continuous Mode Settings as a New Program 3-4
Time Mode 3-5
Time Mode Run Screen 3-5
Time Mode Edit Screen 3-6
Time Mode Operation 3-6
Saving Time Mode Settings as a New Program 3-8
Volume Mode 3-9
Table of Contents
