iv Masterflex
®
I/P
®
MasterSense™ Process Drives Masterflex iv
Table of Contents
Volume Mode Run Screen 3-9
Volume Mode Edit Screen 3-10
Volume Dispense Mode Operation 3-10
Anti-Drip 3-12
Volume Record 3-12
Analog Input Mode 3-13
Analog Input Mode Run Screen 3-13
Analog Input 3-14
Saving Analog Input Mode Settings as a New Program 3-15
Master exLive™ 3-16
Custom Program Modes 3-16
Adding a New Program: Continuous Mode 3-16
Adding a New Program: Time Mode 3-17
Adding a New Program: Volume Mode 3-18
Adding a New Program: Analog Input Mode 3-19
Using Program Modes 3-20
Editing a Program 3-20
Deleting a Program 3-21
SECTION 4: COMMUNICATION SPECIFICATION 41
Ethernet/IP Mode 4-1
Ethernet/IP Setup 4-1
Master ex Ethernet/IP 4-4
Pro bus 4-6
Pro bus Mode 4-6
Pro bus Setup 4-6
Pro bus Settings 4-6
Pro bus data 4-8
SECTION 5: SERVICE & MAINTENANCE 51
Firmware Updates 5-1
Restore Factory Settings 5-1
Cleaning the Pump Drive 5-2
Accessories 5-2
Replacement Parts 5-2
Troubleshooting 5-3
Error De nitions 5-4
31-Pin Electrical Connections 5-5
Speci cations 5-6
Technical Assistance 5-8
Product Return 5-8
Warranty 5-8
Disposal 5-8
