Adding a New Program: Time Mode
To add a new Time Mode program:
1. Tap NEW PROGRAM from the Mode Selection Screen.  e New Program Screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap SCROLL
to view
additional pages.
2. Tap TIME.  e Time New Program Screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
4. Tap ON TIME to set the amount of time for each pump operation.  e On Time Edit Screen will be
displayed.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
5. Tap OFF TIME to set the amount of time the pump will pause between each operation.  e O Time
Edit Screen will be displayed. NOTE: If the o time is set to 0 (zero) the pump drive will require a start
input (from either the touchscreen or a wired input) to start the next dispense.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
6. Tap FLOW RATE.  e Flow Rate Edit Screen will be displayed.
a. Tap UNITS to access the Flow Units Screen and select the desired  ow unit from the available list.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the previous screen.
c. Tap FLOW and enter the desired  ow rate using the onscreen keypad.
d. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
7. Tap SIZE.  e Tube Size Screen will be displayed.
a. Select the desired tube size from the list of available options.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
8. Tap DIRECTION to select either clockwise
or counterclockwise  ow direction.
9. Tap BATCH TOTAL to adjust the number of dispenses in each batch cycle.  e Batch Total Screen will
be displayed.
a. Enter the desired number of dispenses in a batch using the onscreen keypad. NOTE: If required, tap
INFINITE ∞ to select an in nite number of dispense cycles. If in nite is selected, the pump will run
continuously.
b. Tap CONFIRM
to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
10. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
