1-2 Masterflex
®
I/P
®
MasterSense™ Process Drives
Section 1: Introduction
Masterflex
ABOUT THE MASTERFLEX I/P MASTERSENSE
™
e Master ex I/P MasterSense™ Process Drive o ers precise ow control and highly accurate uid
dispensing ideal for pumping high viscous and shear-sensitive liquids. ese pumps are also ideally suited
for use where sterile conditions and purity are required. Toxic and hazardous uids can be pumped with the
proper selection of tubing since the uid contacts only the tubing and not the pump. All I/P precision drives
include a highly accurate, maintenance-free motor and an easy to navigate touchscreen that makes setup and
operation easier than ever. e I/P range features Ethernet and Wi-Fi connections for web-based monitoring
using the Master exLive website (see www.master ex.com), and remote analog input control and monitoring
through the pump drive’s 31-Pin female connection port.
Package Contents
NOTE: Please check the package and its contents for any visible signs of damage. If any damage is found
please contact Technical Assistance immediately (see "Technical Assistance" on page 5-8).
• P
ump Drive
• OHS Cable
• Quick Start Guide
• Flash Drive Containing the Operating Manual
Features
• A 7-inch multi-language touchscreen display providing easy access to user-de ned operation parameters
and direct readouts of pump operation data, including pump speed, ow rates, ow direction, and batch
totals.
• Volume, Time, Continuous, and Analog Input modes for quick and easy operation.
• User selectable dispense volumes, tube diameters, ow rates, pump speeds, and run times.
• Easy user management with three levels of access: ADMIN, SUPER USER and USER.
• Wi-Fi and Ethernet connectivity.
• Brushless, maintenance-free motor o
ering ±0.1% speed control accuracy with a turndown ratio greater
than 4.8:1.
• Easy pump priming and tube calibration.
•
I/P models have a maximum speed of 650 RPM and ow rate capacities that range from .26 LPM
through to 19 LPM (tubing size selected).
