Masterflex I/P MASTERSENSE MFLX77421-00 - Pump Head Selection

2-9 Masterflex
®
I/P
®
MasterSense™ Process Drives
Section 2: Basic Setup & Settings
Masterflex
Deleting a user:
NOTE:  ere must always be at least one ADMIN user. ADMIN users cannot delete their own user pro le.
1. Tap SETTINGS
from any of the mode screens.  e Settings Screen will be displayed.
2. SCROLL
through the Settings Screen pages to locate USER MANAGEMENT.
3. Tap MODIFY USER.
4. Locate the desired username from the available list and then tap the DELETE USER
icon located
next to the username.
5. Tap DELETE to delete user or CANCEL to cancel.
Editing an existing user:
1. Tap SETTINGS
from any of the mode screens.  e Settings Screen will be displayed.
2. SCROLL
through the Settings Screen pages to locate USER MANAGEMENT.
3. Tap MODIFY USER.
4. Select the desired username.
5. Edit as required.
6. Tap CONFIRM
to save or CANCEL to discard any changes.
Pump Head Selection
After changing a pump head, the new pump head must be selected from the Pump Head Settings Screen.
To select a new pump head:
1. Tap SETTINGS
from any of the mode screens.  e Settings Screen will be displayed.
2. SCROLL
through the Settings Screen pages to locate PUMP HEAD.
3. Tap PUMP HEAD.  e Pump Head Settings Screen will be displayed.
4. Select the desired pump head from the list of available options.
5. Tap CONFIRM
to save or CANCEL to discard any changes and return to the Settings Screen.
6. Tap CONFIRM to exit the Settings Screen and return to the previous mode screen.
NOTE: Once the new pump head has been selected, ensure that the appropriate tubing has been selected.
To select a tube size:
1. Tap SIZE from any of the mode screens.  e Tube Size Screen will be displayed.
2. Select the desired tube size from the list of available options. NOTE: Only tube sizes compatible with the
selected pump head will be displayed.
3. Tap CONFIRM
to save or CANCEL to discard changes and return to the mode run screen.
