3-28 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
Section 3: Operation
Masterflex
b. If enabled, enter the desired degrees of reverse rotation using the onscreen keypad. NOTE: Typical
values range from 5 to 45 degrees.
c. Tap CONFIRM to save or CANCEL to discard changes and return to the Volume Mode
Edit Screen.
9. Tap CONFIRM to return to the Volume Mode Run Screen.
10. Tap DIRECTION to select either clockwise or counterclockwise ow direction. NOTE: Flow
Direction is unavailable on single direction gear pumps and will be grayed out.
11. Tap START . e pump will now operate until the batch total is completed or until PAUSE or
STOP is tapped.
12. If required, adjustments can be made to any of the Volume Mode settings during operation. To make any
adjustments:
a. Tap PAUSE and then repeat steps 2–10 above.
b. Tap CONTINUE to complete the pump operation once the desired changes have been made.
Saving Volume Mode Settings as a New Program
Changes made to mode parameters can be saved as a new program for easier access to frequently used settings.
NOTE: If Manage User is enabled only users with authorization can create and modify programs (for further
information see "User Management" on page 3-9).
To save mode parameters to a new program:
1. If required, edit the Volume Mode settings as desired.
2. Tap MODE NAME BANNER to return to the Mode Selection Screen.
3. Tap NEW PROGRAM. NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap
SCROLL to view additional pages.
4. Tap VOLUME. e Volume New Program Screen will be displayed with the last settings used in the
Volume Mode.
5. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
6. Tap CONFIRM to save or DELETE to cancel.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL will display additional pages.
