2-1 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
Section 1: Introduction
Masterflex
ABOUT THE REGLO
e REGLO Digital Pump Drive with Advanced Connectivity oers precise ow control and highly accurate
uid dispensing ideal for laboratory, process, and eld use. All REGLO precision drives include a highly
accurate, maintenance-free motor and an easy to navigate touchscreen that makes setup and operation
easier than ever. e REGLO range features Ethernet and Wi-Fi connections for web-based control and
monitoring using the MasterexLive™ website (see www.masterex.com), and remote analog input control
and monitoring through the pump drive’s DB-25 female connection port.
Package Contents
NOTE: Please check the package and its contents for any visible signs of damage. If any damage is found
please contact Technical Assistance immediately (see "Technical Assistance" on page 3-55).
REGLO Gear Pump
• REGLO Digital Drive Magnet
• 36 VDC Desktop Power Supply Set
• Quick Start Guide
• Flash Drive Containing the Operating Manual
REGLO Piston Pump
• Pump Drive
• 24 VDC Desktop Power Supply Set
• Quick Start Guide
• Flash Drive Containing the Operating Manual
• Pump Head as Ordered
REGLO Drive Features
Features:
• A 5-inch multi-language touchscreen display providing easy access to user-dened operation parameters and
direct readouts of pump operation data, including pump speed, ow rates, ow direction, and batch totals.
• Volume, Time, Continuous, and Analog Input modes for quick and easy operation.
• User selectable dispense volumes, pump head sizes, pump speed, and run times.
• Easy user management with three levels of access: ADMIN, SUPER USER and USER.
• Wi -Fi and Ethernet connectivity.
• Brushless, maintenance-free motor oering ±0.1% speed control accuracy with a turndown ratio greater
than 100:1.
• Easy pump priming and pump head calibration.
