3-39 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
Section 3: Operation
Masterflex
c. Tap CONFIRM to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
10. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL will display additional pages.
Adding a New Program: Analog Input Mode
To add a new Analog Input Mode program:
1. Tap NEW PROGRAM from the Mode Selection Screen. e New Program Screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap SCROLL to view
additional pages.
2. Tap ANALOG INPUT. e Analog Input New Program Screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
4. Tap INPUT. e Analog Type Screen will be displayed.
5. Tap the desired analog type from the available list.
6. If using either ANALOG: VOLTAGE or ANALOG: CURRENT:
a. Select the desired current or voltage operating range from the available list.
b. Tap CONFIRM to save or CANCEL to cancel and return to the Analog Input New Program
Screen.
7. Tap HEAD OPTIONS. e Head Options Screen will be displayed.
a. Select the desired pump head size from the list of available options.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the Analog Input New
Program Screen.
8. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL will display additional pages.
