3-38 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
Section 3: Operation
Masterflex
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
4. Tap VOLUME. e Dispense Volume Screen will be displayed.
a. Tap VOLUME and enter the desired volume using the onscreen keypad. NOTE: If the volume of
uid is unknown the pump drive can record uid dispense volumes (for further information see "Vol-
ume Record" on page 3-29).
b. Tap RAMP UP to set the time the pump takes to reach full ow rate (between 0 and 60 seconds)
using the onscreen keypad.
c. Tap RAMP DOWN to set the time the pump takes to stop at the end of each dispense operation
(between 0 and 60 seconds) using the onscreen keypad.
d. Tap CONFIRM to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
5. Tap INTERVAL TIME to set the amount of time the pump will pause between each operation. e
Interval Time Screen will be displayed. NOTE: If the interval time is set to 0 (zero) the pump drive will
require a start input (from either the touchscreen or a wired input) to start the next dispense.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
6. Tap FLOW RATE. e Flow Rate Edit Screen will be displayed.
a. Tap UNITS to access the Flow Units Screen and select the desired ow unit from the available list.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the previous screen.
c. Tap FLOW and enter the desired ow rate using the onscreen keypad.
d. Tap CONFIRM to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
7. Tap HEAD OPTIONS. e Head Options Screen will be displayed.
a. Select the desired pump head size from the list of available options.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
8. Tap BATCH TOTAL to adjust the number of dispenses in each batch cycle. e Batch Total Screen will
be displayed.
a. Enter the desired number of dispenses in a batch using the onscreen keypad. NOTE: If required, tap
INFINITE ∞ to select an innite number of dispense cycles. If innite is selected, the pump will run
continuously.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the Volume New Pro-
gram Screen.
9. If required, tap ANTI-DRIP. e Anti-Drip Screen will be displayed (for further information see "Anti-
Drip" on page 3-29). NOTE: Anti-Drip is unavailable on gear pumps.
a. Tap ON or OFF to enable or disable the Anti-Drip feature.
b. If enabled, enter the desired degrees of reverse rotation using the onscreen keypad. NOTE: Typical
values range from 5 to 45 degrees.
