Section 3: Operation
Masterflex
4. Tap ON TIME to set the amount of time for each pump operation. e On Time Edit Screen will be
displayed.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
5. Tap OFF TIME to set the amount of time the pump will pause between each operation. e O Time
Edit Screen will be displayed. NOTE: If the o time is set to 0 (zero) the pump drive will require a start
input (from either the touchscreen or a wired input) to start the next dispense.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
6. Tap FLOW RATE. e Flow Rate Edit Screen will be displayed.
a. Tap UNITS to access the Flow Units Screen and select the desired ow unit from the available list.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the previous screen.
c. Tap FLOW and enter the desired ow rate using the onscreen keypad.
d. Tap CONFIRM to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
7. Tap HEAD OPTIONS. e Head Options Screen will be displayed.
a. Select the desired pump head size from the list of available options.
b. Tap CONFIRM to save or CANCEL to discard changes and return to Time New Program
Screen.
8. Tap BATCH TOTAL to adjust the number of dispenses in each batch cycle. e Batch Total Screen will
be displayed.
a. Enter the desired number of dispenses in a batch using the onscreen keypad. NOTE: If required, tap
INFINITE ∞ to select an innite number of dispense cycles. If innite is selected, the pump will run
continuously.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the Time New Pro-
gram Screen.
9. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL will display additional pages.
Adding a New Program: Volume Mode
To add a new Volume Mode program:
1. Tap NEW PROGRAM from the Mode Selection Screen. e New Program Screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap SCROLL to view
additional pages.
2. Tap VOLUME. e Volume New Program Screen will be displayed.
