Masterflex ISMATEC 78018-50 - Custom Program Modes; Adding a New Program: Continuous Mode; Adding a New Program: Time Mode

3-36 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
Section 3: Operation
Masterflex
CUSTOM PROGRAM MODES
Custom programs allow users to create easily accessible programs for frequently used pump mode settings.
NOTE: If Manage User is enabled only users with authorization can create and modify programs (for further
information see "User Management" on page 3-9).
Adding a New Program: Continuous Mode
To add a new Continuous Mode program:
1. Tap NEW PROGRAM from the Mode Selection Screen. e New Program Screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap SCROLL to view
additional pages.
2. Tap CONTINUOUS. e Continuous New Program Screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
4. Select the desired ow rate and ow units:
a. Tap FLOW RATE to access the Flow Rate Screen.
b. Tap UNITS to access the Flow Units Screen and select the desired ow unit from the available list.
c. Tap CONFIRM to save or CANCEL to discard changes and return to the Flow Rate Screen.
d. Tap FLOW and enter the desired ow rate using the onscreen keypad.
e. Tap CONFIRM to save or CANCEL to discard changes and return to the Continuous New
Program Screen.
5. Tap HEAD OPTIONS. e Head Options Screen will be displayed.
a. Select the desired pump head size from the list of available options.
b. Tap CONFIRM to save or CANCEL to discard changes and return to the Continuous New
Program Screen.
6. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL will display additional pages.
Adding a New Program: Time Mode
To add a new Time Mode program:
1. Tap NEW PROGRAM from the Mode Selection Screen. e New Program Screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection Screen tap SCROLL to view
additional pages.
2. Tap TIME. e Time New Program Screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
