F. LOGOUT: Tap to log out a user. NOTE: is option is only available if Manage User is enabled in
Settings (for further information see "User Management" on page 3-9).
Analog Input
!
CAUTION: Power must be turned o before connecting the external analog control cable to
prevent damage to the drive.
e REGLO supports and controls analog input using suitable equipment through the pump drive’s DB-25
female connection port. Analog input can be used in place of, or in addition to, MasterexLive™.
See also "DB-25 Electrical Connections" on page 3-44.
General Preparation:
• Conrm the correct transfer tubing is securely attached to the pump head.
• Conrm all uids and containers are ready.
• Switch the drive on using the power switch located at the rear of the drive. NOTE: If Manage User
is enabled you may be prompted for a Username and Password (for further information see "User
Management" on page 3-9). e touchscreen display will revert to the previously used operation mode.
• Conrm that the pump head has been calibrated (for further information see "Pump Head Calibration" on
page 3-12).
• If required, prime the pump before operation (for further information see "Priming the Pump" on page
3-11).
• Conrm that the pump drive is connected to the appropriate equipment through the drive’s DB-25
female connection port (for further information see "DB-25 Electrical Connections" on page 3-44).
To operate analog input control and monitoring:
1. Tap ANALOG INPUT from the Mode Selection Screen. e Analog Input Mode Run Screen will be
displayed.
2. Tap EDIT . e Analog Input Mode Edit Screen will be displayed.
3. Tap the desired analog input type from the available list.
4. If using either ANALOG: VOLTAGE or ANALOG: CURRENT:
a. Select the desired current or voltage operating range from the available list.
b. Tap CONFIRM to save or CANCEL to cancel and return to the previous screen.
NOTE:
• Tap STOP on the pump drive touchscreen to override the remote control device and immediately stop
the pump operation. NOTE: If locked, the screen will need to be unlocked before the pump operation
can be stopped.
• See www.masterex.com for further information on using analog input remote control and monitoring.
