iv Masterflex REGLO Digital Pump Drive with Advanced Connectivity Masterflex iv
Table of Contents
Mode Selection Screen 3-17
Continuous Mode 3-18
Continuous Mode Run Screen 3-18
Continuous Mode Operation 3-19
Saving Continuous Mode Settings as a New Program 3-20
Time Mode 3-21
Time Mode Run Screen 3-21
Time Mode Edit Screen 3-22
Time Mode Operation 3-22
Saving Time Mode Settings as a New Program 3-24
Volume Mode 3-25
Volume Mode Run Screen 3-25
Volume Mode Edit Screen 3-26
Volume Dispense Mode Operation 3-26
Saving Volume Mode Settings as a New Program 3-28
Anti-Drip 3-29
Volume Record 3-29
Analog Input Mode 3-31
Analog Input Mode Run Screen 3-31
Analog Input 3-32
Saving Analog Input Mode Settings as a New Program 3-33
MasterexLive™ 3-34
MasterexLive™ Run Screen 3-34
Custom Program Modes 3-36
Adding a New Program: Continuous Mode 3-36
Adding a New Program: Time Mode 3-36
Adding a New Program: Volume Mode 3-37
Adding a New Program: Analog Input Mode 3-39
Using Program Modes 3-40
Editing a Program 3-40
Deleting a Program 3-41
SECTION 4: SERVICE & MAINTENANCE 342
Firmware Updates 3-42
Restore Factory Settings 3-42
Flushing the Pump Head 3-43
Cleaning the Pump Drive 3-43
Accessories 3-43
DB-25 Electrical Connections 3-44
Pump Head Replacement 3-45
Available A-Mount Gear Pump Heads 3-45
Available Piston Pump Heads 3-46
