Note

Alternatively, it is also possible to use HRTC - Hardware Real-Time Controller (p. 124) HRTC to set

the master camera. The following sample shows the HRTC - Hardware Real-Time Controller (p. 124)

HRTC program which sets the trigger signal and the digital output.

The sample will lead to a constant frame rate of 16 fps (50000 us + 10000 us = 60000 us for one cycle.

1 / 60000 us ∗ 1000000 = 16.67 Hz).
