22 CONTENTS
mvBlueFOX-120G
1
640 x 480, CCD 1/4", gray
mvBlueFOX-102C
1
1280 x 1024, CMOS 1/2", color
mvBlueFOX-M121C
1
1024 x 768, CCD 1/3", color, module
mvBlueFOX-MLC200wC-XOW-5111 752 x 480, CMOS 1/3", color, single-board, without Mini-USB, 1x IN +
1x OUT opto-isolated, board-to-wire, CS-mount (w/o backfocus adjust-
ment)
1
: -1111 is the standard delivery variant and for this reason it is not mentioned.
6.6 What's inside and accessories
Due to the varying fields of application the mvBlueFOX is shipped without accessories. The package contents:
• mvBlueFOX
• mvIMPACT CD-ROM or DVD-ROM with example application and manual
• instruction leaflet
For the first use of the mvBlueFOX we recommend the following accessories to get the camera up and running:
• A USB 2.0 cable
Attention
According to the customer and if the mvBlueFOX-MLC is shipped without lensholder, the mvBlueFOX-MLC
will be shipped with a protective foil on the sensor. Before usage, please remove this foil!
Accessories for the mvBlueFOX:
Part code Description
ADAPTER CS-MOUNT Lens fixing for mvBlueFOX to match with CS-mount lenses
KS-USB2-AA-EXT 05.0 USB 2.0 extension, activeUSB2 A plug to USB2 A jack, length 5m
KS-USB2-AB 03.0 TR USB 2.0 cable A-B, transparent, Profi Line. Length 3m
KS-USB2-B4ST 02.0 USB 2.0 cable for mvBlueFOX, Binder 4pol to USB2-A. Length: 2m
KS-USB2-B4ST 03.0 USB 2.0 cable for mvBlueFOX, Binder 4pol to USB2-A. Length: 3m
KS-USB2-B4ST 05.0 USB 2.0 cable for mvBlueFOX, Binder 4pol to USB2-A. Length: 5m
KS-USB2-PHR4 01.5 USB connector cable for mvBlueFOX-M1xx. Length: 1.5m
KS-PHR12 500 Cable for mvBlueFOX-M1xx dig. I/O, 12-pin. Length: 500mm
1..4 brown
5..8 gray
9 red
10 black
11 yellow
12 black
KS-MLC-IO-TTL 00.5 mvBlueFOX-MLC board-to-board TTL IO cable for master-slave synchroniza-
tion (Molex plug to Molex plug), Length: 0.5m
MATRIX VISION GmbH
