20.4 mvBlueFOX-[Model]223 (1.4 Mpix [1360 x 1024]) 221

20.4.6 CCD Signal Processing

The CCD signal is processed with an analog front-end and digitized by an 12 bit analog-to-digital converter (A←-

DC). The analog front-end contains a programmable gain ampliﬁer which is variable from 0db (gain=0) to 30dB

(gain=255).
