8.4 Single-board version (mvBlueFOX-MLC2xx) 59
Figure 19: CON3 schematic
8.4 Single-board version (mvBlueFOX-MLC2xx)
8.4.1 Typical Power consumption @ 5V
Model Power consumption (+/- 10%) Unit
-200w 1.09 W
-202a 1.39 W
-202b 1.58 W
-202d 1.28 W
-205 1.37 W
8.4.2 Dimensions and connectors
Figure 20: mvBlueFOX-MLC (without S-mount)
Note
The mvBlueFOX-MLC has a serial I²C bus EEPROM with 16 KByte of which 8 KByte are reserved for the
firmware and 8 KByte can be used to store custom arbitrary data.
See also
UserDataEntry class description
