58 CONTENTS
Manufacturer: JST
Part number: B-2B-PH
8.3.4.1.2 CON3 - Control connector
Pin Signal Comment
1 GND LED2 cathode connector / board ground
2 LED2 output LED2 anode connector1
3 GND LED1 cathode connector / board ground
4 LED1 output LED1 anode connector
5 GND Board ground
6 Input2 Switch to ground for setting Input2
7 GND Board ground
8 Input1 Switch to ground for setting Input1
Manufacturer: JST
Part number: B-8B-PH-SM4 TB
8.3.4.1.3 Electrical characteristic
Signal Parameter Min Typ Max Unit
GND Board ground 0 V
LED 1/2 output (anode)
Output voltage
2
5 V
Internal series resistance 465.←-
3
470 474.←-
4
Ohm
Forward current I
F
at U
LED
= 2V
1
6 mA
Input 1/2 (internal 10k pull up to
3.3V)
Voltage (open contact) 3.3 V
V
IL
(low level input voltage) 0.9 V
V
IH
(high level input voltage) 2.5 5.5 V
Flash +
Voltage (open contact) 23 24 25 V
Flash output capacitance 528 660 792 uF
Internal capacitance storage energy 0.190 Ws
Flash capacitance charge current /
output DC current
20 mA
Flash
2
I
OUT
-2 A
On voltage at I
OUT
MAX 0.15 V
Off voltage 23 24 25 V
1
Depends on mvBlueFOX-M power supply
2
Attention: No over-current protection!
