9.3 Output sequence of color sensors (RGB Bayer) 73
Trigger (Hard-
ware / Soft-
ware)
X / X X / - X / - X / - X / X
Pipelined in
continuous /
triggered mode
X / - X / - X / - X / - X / - (reset only)
High color re-
productivity (for
color version)
X no no no no
Programmable
readout timing
with free cap-
ture windows
and partial scan
X X X X X
Flash con-
trol output,
synchronous
to exposure
period
X no no no no
More specific
data
mvBlueFO←-
X-[Model]200w
(0.4 Mpix [752
x 480]) (p. 231)
mvBlueFO←-
X-[Model]202a
(1.3 Mpix
[1280 x 1024])
(p. 234)
mvBlueFO←-
X-[Model]202b
(1.2 Mpix [1280
x 960]) (p. 237)
mvBlueFO←-
X-[Model]202d
(1.2 Mpix [1280
x 960]) (p. 241)
mvBlueFO←-
X-[Model]205
(5.0 Mpix
[2592 x 1944])
(p. 244)
1
The operation in device specific AEC/AGC mode is limited in (non continuous) triggered modes. AEC/AGC only
works while trigger signal is active. When the trigger signal is removed AEC/AGC stops and gain and exposure will
be set to a static value. This is due to a limitation of the sensor chip.
2
Frame rate increase with reduced AOI width, but only when width >= 560 pixels, below frame rate remains
unchanged.
Note
For further information about rolling shutter, please have a look at the practical report about rolling shut-
ter on our website: https://www.matrix-vision.com/tl_files/mv11/Glossary/art_←-
rolling_shutter_en.pdf
For further information about image errors of image sensors, please have a look at
For further information about image errors of image sensors, please have a look at Correcting image errors
of a sensor (p. 143).
9.3 Output sequence of color sensors (RGB Bayer)
