76 CONTENTS
AOI = 0 degrees
Protective foil on both sides
Without antireflexion
Without bezel
Figure 2: FILTER DL-CUT 15,5X1,5 wavelengths and transmission diagram
Note
For further information how to change the filter, please have a look at our website:
http://www.matrix-vision.com/tl_files/mv11/Glossary/art_optical_filter←-
_en.pdf
10.3 Glass filter
It is also possible to choose the glass filter "FILTER GLASS 15,5X1,75" with following characteristics:
Technical data
Glass thickness 1.75 mm
Material Borofloat without coating
ground with protection chamfer
Surface quality polished on both sides P4
Surface irregularity 5/3x0.06 on both sides
MATRIX VISION GmbH
