9.2 CMOS sensors
The CMOS sensor modules incorporate the following features:
Sensors: 0.4 Mpixels res-
olution CMOS
sensor (-200w)
1.3 Mpixels res-
olution CMOS
sensor (-202a)
1.2 Mpixels res-
olution CMOS
sensor (-x02b)
1
only -MLC/-IGC
1.2 Mpixels res-
olution CMOS
sensor (-202d)
1
only -MLC/-IGC
5.0 Mpixels res-
olution CMOS
sensor (-205)
Sensor supplier Aptina Aptina Aptina Aptina Aptina
Sensor name MT9V034 MT9M001 MT9M021 MT9M034 MT9P031
Resolution 752 x 480
gray scale or
RGB Bayer mo-
saic
1280 x 1024
gray scale
1280 x 960
gray scale or
RGB Bayer mo-
saic
1280 x 960
gray scale or
RGB Bayer mo-
saic
2592 x 1944
gray scale or
RGB Bayer mo-
saic
Indication of
sensor cat-
egory to be
used
1/3" 1/2" 1/3" 1/3" 1/2.5"
Pixel clock 40 MHz 40 MHz 40 MHz 40 MHz 40 MHz
Max. frames
per second (in
free-running full
frame mode)
93
2
25 25 25 5.8
Binning H+V (frame rate
170 Hz)
H+V, Average←-
H+V (frame rate
unchanged)
H+V, Average←-
H+V (frame rate
unchanged)
H+V, Average←-
H+V (frame rate
unchanged)
H+V, 3H+3V,
AverageH+V,
Average3H+3V,
DroppingH+V,
Dropping3←-
H+3V (frame
rate 22.7 Hz)
Exposure time 6 us - 4 s 100 us - 10 s 10 us - 4 s 10 us - 4 s 10 us - 10 s
ADC resolution 10 bit (10 / 8 bit
transmission)
10 bit (10 / 8 bit
transmission)
10 bit (10 / 8 bit
transmission)
10 bit (10 / 8 bit
transmission)
10 bit (10 / 8 bit
transmission)
SNR 42 dB 40 dB < 43 dB 37.4 dB
DR (normal /
HDR (p. 161))
55 dB / > 110
dB
61 dB / - > 61 dB / > 61 dB / >
110 dB (with
gray scale
version)
65 dB /
Progressive
scan sensor
(no interlaced
problems!)
X X X X X
Rolling shutter - X - X X
Global shutter X - X - X
