• To create a group of sequential FXS Ports as members,
• Select the desired FXS Port numbers as members. Default: 1.
• In the in - order field, select the order in which the system should check for a free member FXS
Port to route the call.
Select Ascending to start checking from the first to the last member FXS Port. Select
Descending to start checking from the last to the first member FXS Port. Default: Ascending.
• To create a group of not-sequential FXS Ports as members,
• Select a FXS Group.
• Select FXS Group number. Default:1.
• Click Settings . The FXS Groups window opens. Create the FXS Group. See “Group” for
detailed instructions.
• Similarly, you can create group of sequential and not-sequential FXO Ports as members.
• You may create the Fallback Routing Group. To do this,
• Select the Apply check box.
• Follow the same instructions for creating sequential and not-sequential groups, for FXS Ports and
FXO Ports.
• Click Submit to save changes. The Add Entry window closes.
• The entry you added appears in the SIP Trunk - Destination Port Determination - Destination
Number Based window.
• By default FXS Port 1-1 (Ascending) is assigned as the Routing Group, for routing calls from numbers
that do not match with any of the destination numbers you configured, that is the No Match Found
entry.
To change the default Routing Group and to create the Fallback Routing Group for the No Match Found
numbers,
