TORQUE VALUES FOR HYDRAULIC CONNECTORS
STEP 8 - RUN HYDRAULIC LINES & ELECTRIC CABLES
- Continued
SIZE TORQUE (LB-FT) TORQUE (NEWTON-METER)
-4 13-15 17.6-20.3
-6 22-24 29.8-32.5
-8 40-43 54.2-58.3
TABLE 50-1
SAE O-RING CONNECTORS
SIZE TORQUE (LB-FT) TORQUE (NEWTON-METER)
-4 11-12 14.9-16.3
-6 18-20 24.4-27.1
-8 36-39 48.8-52.8
TABLE 50-2
SAE 37 DEGREE FLARE CONNECTORS
SIZE TORQUE (LB-FT) TORQUE (NEWTON-METER)
-4 17-18 23-25.4
-6 25-27 33.9-37.3
-8 38-41 51.5-56.7
TABLE 50-3
O-RING FACE-SEAL CONNECTORS
