Maxon BMR Series - Pump & Motor Solenoid Operation - Gravity Down

97
11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
PUMP & MOTOR SOLENOID OPERATION - GRAVITY DOWN
TABLE 97-1
HYDRAULIC SYSTEM DIAGRAMS
POWER UNIT MOTOR & SOLENOID OPERATION - GRAVITY
DOWN
LIFTGATE
FUNCTION
PORT
SOLENOID OPERATION ( MEANS ENERGIZED)
SWITCH RELAY MOTOR
VALVE
“B”
VALVE
“D”
VALVE
“E”
VALVE
“H”
LIFT B
“GD”
-----
LOWER C - - -
OPEN J - - -
CLOSE A - - - -
REFER TO VALVES SHOWN ON HYDRAULIC SCHEMATIC
“D” VALVES
(TOP OF EACH COLUMN)
FIG. 97-3
“M” SOLENOID
“E” VALVE
“H” VALVE
FIG. 97-1
“D” VALVE
BUCHER PUMP “B” VALVE
FIG. 97-2
“B” VALVE
“B” VALVE
