STEP 19 - PLATFORM CHAIN ADJUSTMENT -
Continued
4. Raise platform enough to remove
supports. Then, lower platform to the
ground (FIG. 89-1). Tip of fl ipover
and runners should touch the ground
at the same time as shown in FIG.
89-1. If necessary, repeat instruc-
tions 3 and 4 until tip of platform and
runners touch ground at the same
time.
TIP OF
FLIPOVER
BOTTOM OF
RUNNER
GROUND
TIP AND RUNNER TOUCHING GROUND
FIG. 89-1
