Demonstration Test Groups
To enable you to get started, ten test Groups have been included to cover a variety of equipment types. They may be used, deleted or modified at any time.
CODE USAGE TESTS APPLIED PASS LIMITS SET
SC1 Standard Class 1 Visual Inspection
Earthed Equipment Earth Bond at 10A 0.1Ω or less
Insulation 2.0MΩ or more
Operation (230V) 3kVA or less
Earth Leakage (230V) 3.5mA or less
SC2 Typical Class 2 Visual Inspection
Double Insulated Insulation 7.0MΩ or more
Operation (230V) 3kVA or less
Earth Leakage 0.5mA or less
TO1 110 V Tools Visual Inspection
Earthed at 25A Earth Bond 0.1Ω or less
Insulation 2 MΩ or more
Operation (110V) 2 kVA or less
Earth Leakage (110V) 3.5 mA or less
TO2 110 V Tools Visual Inspection
Double Insulated Insulation 7 MΩ or more
Operation (110V) 2 kVA or less
Earth Leakage (110V) 0.5 mA or less
EL1 230V Extension Leads Visual Inspection
3 Core Earth Bond at 25A 0.5Ω or less
Insulation 7 MΩ or more
Polarity Correct polarity of conductors
EL2 230V Extension Leads Visual Inspection
2 Core Insulation 5 MΩ or more
Polarity Correct polarity of conductors
FAN Desk Fan Visual Inspection
Double Insulated Insulation 7 MΩ or more
Operation Test (230V) 200 VA or less
Earth Leakage (230V) 0.5 mA or less
PC Personal Computer Visual Inspection
IT Equipment Earth Continuity 0.1Ω or less
Operation (230V) 500 VA or less
Earth Leakage (230V) 3.5mA or less
DRY Hairdryers Visual Inspection
Double Insulated Insulation 7 MΩ or more
Operation (230V) 1.5 kVA or less
Earth Leakage (230V) 0.5 mA or less
KET Kettles Visual Inspection
Earthed Earth Bond at 25A 0.1 Ω or less
Insulation 2.0 MΩ or more
Operation (230V) 2.5 kVA or less
Earth Leakage (230V) 3.5mA or less
EL3 110V Extension Leads Visual Inspection
3 Core Earth Bond at 25A 0.5Ω
or less
Insulation 7 MΩ or more
Polarity Correct polarity of conductors
