8
PAT4 accepts up to ten User names / PIN numbers at any one time, allowing only authorised persons to use the unit, if required. To input User names
and their respective pin numbers see ‘Settings’. Tests are attributed to the user that is currently logged in.
If you have not used the
PAT4 before:
1 Type in the name AVO. Typing errors can be deleted using the
ESC/DEL key. Press the OK key.
2 Type in the PIN number 1234 and press the
OK key. The current Client will be briefly displayeD
followed by the Client screen.
3 Press the
SELECT key. The Client Selection screen is displayed.
4 Press the NEXT key repeatedly. Each time the key is pressed, the next Client is displayed.
5 When the screen displays the desired client, press the
OK key. This selects the displayed client as
the current client. The ‘Location‘ screen is now displayed.
6 Press the
SELECT key in order to view and choose the site or building location.
7 Press the
NEXT key repeatedly. Each time the key is pressed the next location within
the selected client is displayed.
8 When the screen displays the desired location, press the
OK key.
This selects the displayed location as the site location you are currently using.
The Main screen is displayed.
Main Screen
The Client and Location need be selected only once for any particular site. PAT4 will assume the same settings until you deliberately logout from the Client. Even
if mains power is removed e.g. when moving around a site, if you have not logged out, the PAT4 will automatically return to the Main screen.
Logging in to the Unit
User:AVO
PIN: *
Client SELECT
LOGOUT ACCEPT
NEXT Client MORE
AVO INTERNATIONAL
Location SELECT
LOGOUT
NEXT Location MORE
ASHFORD SITE
TESTS QUICK-CHECK
COMMS MENU
