AVTMTTR310 Rev 8 May 2016

CHECK PHASE A (or B, or C) POLARITY

This message shows that the H or X test leads are incorrectly connected or the

test transformer connections or markings do not comply with the requirements

of ANSI, IEC, or the Australian standard.

If self-test fails, one of the following error messages will appear on the opening

display screen and you should return the test set to Megger for repair. Refer to

Repair section for instructions.

ANALOG OFFSET VOLTAGE HIGH

ANALOG GAIN OUT OF TOLERANCE

CAN NOT DETECT FLASH RAM

FAILED PROGRAM CODE CHECK

PLEASE SHUT DOWN AND CHECK THE MANUAL

CHECKING ALTERA: GOOD (BAD)

CHECKING DISPLAY: GOOD (BAD)

CHECKING RAM: GOOD (BAD)
