Megger TTR310 - Specifications; Electrical Specifications

To Next Page

To Previous Page

AVTMTTR310 Rev 8 May 2016

Specifications

Electrical

Input Power

Cat. No. TTR310/TTR310E: 120 V ac ±10%, single phase, 60 ±2 Hz, 100 VA

IEC 1010-1 installation category II

Cat. No. TTR310-47/ TTR310E-47: 230 V ac ±10%, single phase, 50 ±2 Hz, 100 VA

IEC 1010-1 installation category II

Pollution Degree

TTR310 is designed for Pollution Degree II

Protective Devices

Fuses (2)*:

Cat. No. T TTR310/TTR310E:: Type T, 250 V, 1A (IEC 127 designation)

Cat. No. TTR310-47/ TTR310E-47:: Type T, 250 V, 0.5 A (IEC 127 designation)

High voltage and low voltage measurement circuit shorting relays

Heavy duty varistors and transient voltage suppressors

* Two spare fuses are included with each TTR310 as spare parts

Output Test Voltage and Current

3 test voltages: 80 V rms, 40 V rms, 8 V rms.

Current: up to 500 mA

Test Frequency

Same as line frequency.
