AVTMTTR310 Rev 8 May 2016

116

Repair

Megger offers a complete repair and calibration service and recommends that its

customers take advantage of this service in the event of equipment malfunction.

Contact your MEGGER representative for instructions and a return

authorization (RA) number. Equipment returned for repair should be shipped

prepaid and insured and marked for the attention of the Repair Department.

Please indicate all pertinent information including problem symptoms and

attempted repairs. The catalog number and serial number of the test set should

also be specified. Pack the TTR310 test set, including all cables, in a carton

(original shipping carton if available) with adequate dunnage in accordance with

best commercial practice. Seal the carton with waterproof tape.

Ship to: M

Valley Forge Corporate Center

2621 Van Buren Avenue

Norristown, PA 19403 U.S.A.
