Megger TTR310 - Main Menu Screen When a Custom Transformer Setting Recalled (Figure 6-10); Figure 6-10. the Main Menu Screen after Selection of a Custom Transformer Setting

M
AVTMTTR310 Rev 8 May 2016
82
Main Menu Screen When a Custom Transformer Setting Recalled
(Figure 6-10)
After selection of a custom transformer setting, the MAIN MENU will appear as
shown in Figure 6-10. It will display the main parameters of the saved custom
settings, including the H and X nameplate voltages, the diagram number and the
test set voltage. The ID number will be blank. The test number shows the
number of the next test to be run.
MAIN MENU
DATE (M/D/Y) : 06/15/1998 14:15
1 QUICK TEST SETUP TEST WINDING:
2 FULL TEST SETUP
3 RECALL CUSTOM SETTINGS * 7 H-X
4 SYSTEM SETUP MENU 8 H-Y
5 SAVED DATA MENU 9 CT
6 PRINT HEADER
TEST:002 ID nnnnnnnnnnnn DIAG 01 1ph0
TEST VOLTAGE: AUTO
H NAMEPLATE VOLTAGE (L-L): 250000
X NAMEPLATE VOLTAGE (L-L): 50000
ENTER SELECTION FROM KEYPAD
Figure 6-10. The Main Menu Screen After Selection of a Custom Transformer Setting
Full Test Setup 1, 2, and 3 screens will display the custom transformer setting
recalled.
