OPERATION
AVTMTTR310 Rev 8 May 2016
89
Use with the Optional Printer
If you are using the optional printer, plug the printer cable into the
RS232/PRINTER receptacle on the TTR310 test set and turn it on. A separate
manual is supplied with the printer. Refer to it for specific information about
how to connect, operate, and care for the printer.
Select 6 PRINT HEADER on the main menu to print out a test report header.
Select 1 PRINT on the final quick test result screen or the three-phase
transformer test result screen to print out test results. A sample printout is
shown in Figure 6-15a, 6-15b, and
6-15c.
M
AUTOMATIC TRANSFORMER TURN RATIO TESTER
CATALOG NO. TTR310
________________________________________________
TRANSFORMER TEST REPORT
COMPAMY:______________________________________
SUBSTATION:____________________________________
MANUFACTURER:________________________________
TRANSFORMER RATING:________________kVA/MVA
AMBIENT TEMPERATURE:________________________
RELATIVE HUMIDITY:____________________________
TTR S/N:__9901245_______________________________
OPERATOR (S):___________________________________
_________________________________________________
COMMENTS/NOTES:
Figure 6-15a. Sample Test Report Header
DATE (M/D/Y) : 06/01/1999 12:25
TEST: 002
TRANSFORMER ID: 12A-76M/2
TYPE: SINGLE PHASE TRANSFORMER 1ph0
TAPS TESTED: 3 – 17
H VOLTAGE: 10000
X VOLTAGE: 10000
CALCULATED TURNS RATIO: 1.0000
TEST VOLTAGE: 8V
RATIO 1.0013
% DEVIATION 0.13
PHASE(min) -14.7
Iexc(ma) 0.03
Figure 6-15b. Sample Single Phase Test Report
