Recall (or Save) Custom Transformer Settings (Figure 6-14)
If 3 (RECALL CUSTOM SETTINGS) is selected on the MAIN MENU screen
(Figure 6-1), the RECALL CUSTOM SETTINGS screen appears as shown in
Figure 6-14.
If 8 (SAVE CUSTOM SETTINGS) is selected on the FULL TEST SETUP 2
menu (Figure 6-6), the screen appears the same as in Figure 6-14 except that the
headline will be changed to SAVE CUSTOM SETTINGS.
RECALL CUSTOM SETTINGS
DIAG TYPE H VOLTAGE X VOLTAGE
1 03 Dd0 250000 20000
2
3 12 Dyn5 67000 12000
4
5
6
7
8
9
0 PREVIOUS MENU
ENTER SELECTION FROM KEYPAD
Figure 6-14. Recall (or Save) Custom Settings Screen
The following message will be displayed if a selection without data is recalled:
NO DATA IN SELECTED CUSTOM SETTING, PRESS ANY KEY TO
CONTINUE.
The following message will be displayed if your selection to save data already
contains data:
CUSTOM SETTING 1 (i.e.) HAS DATA! OVERWRITE? 0 = YES, 1 = NO
Saved data will be overwritten by selecting YES.
Selecting NO will return you to the SAVE CUSTOM SETTINGS screen.
