Megger TTR310 - Operation

To Next Page

To Previous Page

AVTMTTR310 Rev 8 May 2016

Operation

General Operating Procedure

Proceed only after reading and fully understanding Section 2, Safety, and setting

up the test set as described. An operator who is familiar with the contents of this

manual, the test setup, and the operation of the test set may follow the

condensed operating instructions in the lid of the test set.

EMERGENCY SHUTDOWN

Press red EMERGENCY TEST OFF push button or switch power

off.

Description of Menus and Test Screens

Data shown on the menus and test screens in Figures 6-1 through 6-16 are for

illustrative purposes only. The TTR310 test set menus and test screens are

operated by using the keypad on the front panel. On power up, a beep sounds,

the test set performs a self-test check, and all hardware and software variables are

initialized.

Main Page
