THREE PHASE TRANSFORMER TEST
TEST: nnn ID:A13579CV0246 DIAG nn Ddnnn
TEST VOLTAGE: 80V
A B C
RATIO 12.379 12.354 12.287
PHASE (min) 4.8 5.1 2.3
Iexc (mA) 2.6 2.9 2.2
SELECT: 1-PRINT 2-STORE 3-NEXT TEST
4-REPEAT TEST 5-MAIN MENU
Figure 6-4. Final Quick Test Result Screen
1 PRINT: This selection allows the test result to be printed out (on
an optional printer or uploaded to PC.
2 STORE: This selection allows the test result to be saved in
memory for future viewing and/or printing and/or
uploading to PC.
3 NEXT TEST: When selected, the QUICK TEST SETUP screen,
Figure 6-2, appears. You may change connections and
continue testing with the same transformer (for example,
with a different tap of the high voltage winding) or you
may start testing a new transformer.
4 REPEAT TEST: This selection allows you to repeat the last test.
5 MAIN MENU: This selection brings back the MAIN MENU screen
(Figure 6-1).
