FULL TEST SETUP 3 Screen (Figure 6-7)
If 1 is selected on the FULL TEST SETUP 2 screen, the FULL TEST SETUP 3
screen appears (Figure 6-7).
Figure 6-8. FULL TEST SETUP 3 Screen
The test number, ID and diagram are shown on the first line.
Selections 1 and 2 allow you to test any pairs of H and X taps. If the transformer
under test does not have any taps, only selections 3, 4, and 5 will be displayed on
the screen.
If 3 (START TEST) is selected, see Figure 6-3 for the next screen displayed.
The % DEVIATION heading will also be shown on the screen.
1 H TAP TO BE
TESTED:
This selection is used to enter the H tap number to be
tested when test winding 7 H-X or 8 H-Y is selected on
the Main Menu screen (see Figure 6-1).
When test winding 9 CT is selected on the Main Menu
screen this entry will go off.
2 X TAP TO BE
TESTED:
This selection is used to enter the X tap number to be
tested when test winding 7 H-X is selected on the Main
Menu screen (see Figure 6-1). When test winding
8 (H-Y) is selected on the Main Menu screen, entry 2 X
TAP TO BE TESTED is replaced by 2 Y TAP TO BE
TESTED. When test winding 9 CT is selected on the
Main Menu screen (see Figure 6-1), this entry will go off.
3 START TEST: This selection initiates testing of a transformer. If
selected, the screen shown in Figure 6-3 will appear.
FULL TEST SETUP 3
TEST: nnn ID:A13579CV0246 DIAG nn Ddnnn
1 H TAP TO BE TESTED: 3
2 X TAP TO BE TESTED: 3
3 START TEST
4 PREVIOUS MENU
5 MAIN MENU
ENTER SELECTION FROM KEYPAD
