SYSTEM SETUP Menu (Figure 6-11)
When selection 4 (SYSTEM SETUP MENU) on the MAIN MENU is chosen,
the SYSTEM SETUP MENU screen appears as shown in Figure 6-11.
Figure 6-11. SYSTEM SETUP Screen
1 LANGUAGE: This selection allows a choice of six languages. See
Figure 6-12 for LANGUAGE screen.
2 SET DATE/TIME: This selection is for entering the date and time. Year has
four-digit representation (mm/dd/yyyy).
3 STANDARD: This selection is for entering the desired transformer
standard. Three transformer standards are available to
select from: ANSI, IEC, or AS (Australia Standard).
4 TEST VOLTAGE: This selection is for entering the desired test voltage.
There are four selections available:
AUTO the TTR310 will automatically test at the
highest allowable excitation voltage (80 V, 40 V, or 8 V),
depending on the transformer excitation current
measured.
80 V the test voltage is 80 Volts.
40 V the test voltage is 40 Volts.
8 V the test voltage is 8 Volts.
SYSTEM SETUP
1 LANGUAGE: ENGLISH
2 SET DATE (M/D/Y)/TIME: 03/16/1998 11:45
3 STANDARD: ANSI
4 TEST VOLTAGE: AUTO
5 PHASE DISPLAY: DEGREES
6 MAIN MENU
ENTER SELECTION FROM KEYPAD
