MAIN MENU Screen (Figure 6-1)
After a successful self-test check, the main menu screen (Figure 6-1) appears.
MAIN MENU
DATE (M/D/Y) : 06/15/1998 14:15
1 QUICK TEST SETUP TEST WINDING:
2 FULL TEST SETUP
3 RECALL CUSTOM SETTINGS * 7 H-X
4 SYSTEM SETUP MENU 8 H-Y
5 SAVED DATA MENU 9 CT
6 PRINT HEADER
TEST:002 ID nnnnnnnnnnnn DIAG
01
1ph0
TEST VOLTAGE: AUTO
H NAMEPLATE VOLTAGE (L-L): 250000
X NAMEPLATE VOLTAGE (L-L): 50000
ENTER SELECTION FROM KEYPAD
Figure 6-1. Main Menu Screen
DATE (M/D/Y): This line shows the current date and time. Date
format is month/day/year. To change date/time,
select 4 (SYSTEM SETUP MENU) and then
select 2 (SET DATE(M/D/Y)/TIME) on the
SYSTEM SETUP menu (see Figure 6-11).
1 QUICK TEST SETUP: This setup provides a quick path for transformer
testing. It requires minimum transformer nameplate
information to be entered before testing. The test
results displayed do not include the calculated ratio
and ratio deviation values.
2 FULL TEST SETUP: This setup requires entering main transformer
nameplate information. The FULL TEST SETUP is
used for obtaining full test information of a
transformer. This setup may be saved and recalled
later for future testing of the same or similar type
transformers. In this case (RECALL CUSTOM
SETTINGS), no additional information needs to be
entered to start testing, other than the transformer
serial number (TRANSFOMER ID) if desired.
