8. The readings for phases A, B, and C should be:

RATIO: 1.0000 ±0.0020

PHASE(min): 0 ±5

Iexc (mA): 0.0 to 0.5

If needed, perform the test according to steps 1 through 8 for the excitation

voltage 40 V, and then for the excitation voltage 8 V. The readings should be the

same as shown in step 8.
