M
AVTMTTR310 Rev 8 May 2016
12
Physical Data
Dimensions:
Instrument:
Case:
8.5 H x 21.5 W x 13 D in (216H x 546.1 W x 330.2 D
mm)
25 H x 19 W x 26 D in. (635 H x 483 W x 660 D
mm)
Weight (test set):
Instrument with standard
provided accessories
Instrument with Optional Leads
30 ft (9.1 m)
Instrument with Standard
accessories and Transit Case
Instrument with Optional Leads
and Transit Case
25 lbs (11.3 kg)
47 lbs (21.3 kg)
62 lbs (28.1 kg)
84 lbs (38.1 kg)
Transit Case: Black ABS case with lid
37 lb (16.7 kg)
Accessories Supplied
Item (Qty) Cat. No.
Three-Phase TTR
®
310 Test Set, fully automatic, self-
checking, self-calibrating, menu-driven unit
120 V ac ±10%, single phase, 60 ±2 Hz, 100 VA
IEC 1010-1 installation category II
TTR310/TTR310E
230 V ac ±10%, single phase, 50 ±2 Hz, 100 VA
IEC 1010-1 installation category II
TTR310-47/TTR310E-47
Included Accessories
Canvas carrying bag for test leads 2005-265
Power supply cord, 8 ft (2.5 m) (120 version units) 17032-4
Power Supply cord, 8 ft (2.5 m) (230 version units) 17032-13
Ground lead, 15 ft (4.6 m) 4702-7
