Table 5-5. CEI/IEC 76-1:2011 Transformer Winding Phase Relationship
Copyright 2009  Megger
Winding Connection Winding Tested
Diag
No.
IEC
Vector
Group
High-Voltage
Winding (U1)
Low-Voltage
Winding (U2)
Phase
Tested
Winding
Shorted
By TTR
High-
Voltage
Winding
Low-
Voltage
Winding
Measured
Turn Ratio Remarks
51 YNd11
U
V
W



1U-1N
1V-1N
1W-1N
2U-2W
2V-2U
2W-2V
32U
1U
v
Neutral
accessible
on wye
winding
52 Yd11
U
V
W
1V-1W
1W-1U
1U-1V
1U-(1V+1W)
1V-(1W+1U)
1W-(1U+1V)
2U-2W
2V-2U
2W-2V
32U
5.1*1U
v
No neutral
accessible
on wye
winding
