SETUP AND CONNECTIONS
AVTMTTR310 Rev 8 May 2016
59
Additional Transformer Winding Identification
External terminal markings for three-phase power transformers with more than
two windings are as follows:
3A, 3B, 3C Third winding (if any).
4A, 4B, 4C Fourth winding (if any).
If unable to find a corresponding diagram for a transformer with, for example,
accessible neutral winding but can find the corresponding diagram for the same
transformer with no neutral accessible winding, follow the test procedure for the
transformer with no neutral accessible winding. In this case, specify the diagram
number for the transformer with no neutral accessible winding and do not
connect N or n lead to the neutral.
As an example, if transformer winding connection is identical to Table 5-6
Diagram No. 23 except the wye winding has an accessible neutral winding,
perform test per Diagram 23. Do not connect N lead to the wye winding neutral
terminal. The test results are identical and do not require any corrections.
