Meggitt vibro-meter VM600 Quick Start Manual

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600
Mk2
machinery protection system (MPS) Edition 2 - February 2021
vi
Who should use this manual?
The manual is intended for use by qualified personnel, such as operators of process
monitoring/control systems using a VM600
Mk2
machinery protection system (MPS).
NOTE: Personnel involved in the installation, operation and maintenance of Meggitt
vibro-meter
®
systems are assumed to have the necessary technical training in
electronics and/or mechanical engineering (professional certificate/diploma or
equivalent) to enable them to install, configure, use and/or maintain the system
correctly and safely.
Applicability of the manual
The manual is applicable to the VM600
Mk2
machinery protection system (MPS) using
MPC4
Mk2
+IOC4
Mk2
machinery protection and condition monitoring modules and optional
RLC16
Mk2
relay modules, that is, the evolution of the VM600 MPS based on existing VM600
rack infrastructure.
Different versions of VM600
Mk2
/VM600 MPS racks and modules can be visually identified
from the front panels of the rack and modules. For each module, the lower handle on the front
panel includes the module’s name.
For a VM600
Mk2
MPS, the main modules are:
•MPC4
Mk2
+IOC4
Mk2
machinery protection and condition monitoring module
• RLC16
Mk2
relay module.
Users of a VM600
Mk2
MPS should use this VM600
Mk2
machinery protection system (MPS)
quick start manual and refer to a VM600 machinery protection system (MPS) hardware
manual, as required.
For reference, for a VM600 MPS, the main cards (modules) are:
• MPC4/IOC4T machinery protection card pair
• RLC16 relay card.
Users of a VM600 MPS should refer to the VM600 machinery protection system (MPS)
quick start manual and a VM600 machinery protection system (MPS) hardware manual, as
required.
